Multiple welding modes
Compact structure with lightweight design
User-friendly interface with Windows 7 operating system
Password protection and parameter program storage
Barcode scanning function: supports both barcode and QR code
Comprehensive process data storage to enable product traceability
Supports sequential welding control and unit operation
Supports networked control and data monitoring
Multiple desktop configurations for various production settings
Supports integration into production lines
Equipment power options: 2000W, 4200W, 5600W, 8000W. It enables one-time welding forming for wire harnesses with cross-sectional areas ranging from 0.5mm² to 70mm². (We will continue to develop wire harness welding machines capable of welding wire harnesses with larger cross-sectional areas.)
Integrated design for the entire machine, featuring small structure volume, lightweight, elegant appearance, and easy mobility. Adopts PLC phase-locked frequency automatic tracking technology to ensure stable welding effects between wire harnesses, as well as between wire harnesses and terminal plates.
Realizes wire harness connection at minimum cost. After welding, it delivers excellent electrical conductivity with low or nearly zero resistivity. It has short welding time and requires no flux, gas, or solder, making it a currently environmentally friendly welding process and advanced electrical connection technology.
| Brand | WEIJIANG |
| Product | Ultrasonic Metal Welder |
| Model | WU-HN525 |
| Air Pressure | 0.05-0.6 MPA |
| Operating Frequency | 20 KHZ |
| Welding Range | 5-25 mm² |
| Terminal Thickness | ≤3 mm |
| Dimensions | 65*35*78cm |
| Frame Weight | 142 KG |
| Power Supply | 220V |
| Application | Copper wires, aluminum wires, copper-aluminum terminals |
| Motor Power | Customizable |
