Functions

Wire Processing Function

• Capable of handling wires and cables with a diameter ≤ Φ18mm. Compatible with spools up to 380mm in width, 100-400mm in outer diameter, and 38-45mm in inner diameter, with a maximum load of 60kg to meet the wire feeding needs of different spool specifications.

• The wire feeding speed is adjustable from 0-4m/s, controlled by a frequency converter to adapt to the different production rhythms of equipment such as computer wire stripping machines.

Intelligent Sensing and Synchronization Control Function

• Automatic Speed Adjustment: Through multi-stage speed control of the frequency converter, the wire feeding speed is automatically sensed and adjusted based on the lifting height of the storage wheel without manual intervention, ensuring synchronization between wire feeding and the wire stripping machine.

• Speed Feedback Closed Loop: When the tension wheel moves with the wire, it drives a potentiometer to rotate via a sprocket, sending real-time feedback signals to the frequency converter to precisely control the speed of the wire feeding motor and avoid wire stretching or slack.

Tension Adjustment Function

• The tension wheel set (3 upper fixed wheels and 2 lower movable wheels, 140mm in diameter) applies uniform tension through multi-wheel contact. The tension can be linearly adjusted by changing the position of the counterweight block (using the principle of leverage) to adapt to the tension requirements of different wires.

Power Supply and Drive Function

• Supports wide voltage input of 220V/110V and frequency of 50/60Hz, suitable for power grids in multiple regions. Adopts a drive combination of “frequency converter + motor + speed reducer” to achieve precise power control and efficient transmission.

Features

High Automation Level

• The sensing adjustment and speed feedback systems realize fully automated processes, reducing manual operations, human errors, and improving production efficiency.

Strong Compatibility

• Compatible with various wire diameters, spool specifications, and power standards, suitable for multi-scenario operations such as electronic wire harness processing and cable production.

Precise Tension Control

• The combination of mechanical structure (multi-wheel set design) and counterweight adjustment ensures simple and high-precision tension adjustment, avoiding excessive wire stretching or slack and guaranteeing processing quality.

Robust and Durable Structure

• The main frame is made of high-quality carbon steel through sheet metal bending and welding, with strong impact resistance, beautiful surface treatment, and suitability for long-term high-load operation in industrial environments with low maintenance costs.

Stable and Reliable Operation

• The drive system (frequency converter + motor + speed reducer) provides stable power output, and the speed feedback closed-loop control ensures the synchronization between wire feeding and equipment, reducing wire loss.

Easy Operation

• Tension adjustment is achieved through physical counterweight blocks without complex parameter settings; the sensing system operates automatically, reducing the technical requirements for operators.
